GEEKOM IT15 Mini PC | Intel® Core™ Ultra 9 285H

In stock

AI Performance. Desktop-Class Power. Mini PC Design.

The GEEKOM IT15 delivers next-generation Intel® Core™ Ultra performance in a compact professional desktop. Powered by the Intel® Core™ Ultra 9 285H with Intel® Arc™ 140T graphics, 32GB DDR5 memory, a 1TB PCIe Gen 4 SSD, Wi-Fi 7, dual USB4 and 2.5GbE networking, it is designed for demanding productivity, AI-assisted workloads, content creation and professional computing.

26 in stock

SKU: GEEKOMU5125U16512-3 Category:

Description

Key Specifications

Processor: Intel® Core™ Ultra 9 285H – 16 Cores / 16 Threads, up to 5.4GHz
Graphics: Intel® Arc™ 140T Graphics
Memory: 32GB Dual-Channel DDR5 SO-DIMM
Storage: 1TB M.2 2280 PCIe® Gen 4×4 NVMe SSD
Operating System: Windows 11 Pro
Wireless: Wi-Fi 7 + Bluetooth® 5.4
Ethernet: 1× 2.5GbE RJ45
Display Outputs: 2× HDMI 2.0 + 2× USB4 Display Support
USB4: 2× USB4 Type-C (40Gbps)
USB: 3× USB 3.2 Gen 2 Type-A + 1× USB 2.0 Type-A
Card Reader: 1× SD 4.0 Card Reader
Audio: 1× 3.5mm Stereo Headset Jack
Security: Kensington Lock + dTPM 2.0
Power: 120W (19V / 6.32A)
VESA Mount: Supported
Dimensions: 117 × 112 × 49.2 mm

Expansion

Memory: 2× DDR5 SO-DIMM slots
Primary Storage: 1× M.2 2280 PCIe® Gen 4×4 NVMe SSD slot
Additional Storage: 1× M.2 2242 SATA III SSD slot
2.5″ Storage: 1× 2.5″ SATA HDD/SSD bay

Connectivity Highlights

Wi-Fi 7 + Bluetooth® 5.4
Next-generation wireless connectivity

2.5GbE LAN
Fast and reliable wired networking

Dual USB4 40Gbps
High-speed data, display and peripheral connectivity

Multi-Display Support
Flexible multi-monitor connectivity through HDMI and USB4

SD 4.0 Card Reader
Fast media transfer for professional workflows

Performance Highlights

Intel® Core™ Ultra 9 285H
High-performance 16-core processor with boost speeds up to 5.4GHz

Intel® Arc™ 140T Graphics
Powerful integrated graphics for professional and creative workloads

AI-Ready Architecture
Integrated Intel® AI Boost NPU for compatible AI workloads

High-Speed DDR5 Memory
32GB dual-channel DDR5 for demanding multitasking

Advanced Cooling
Designed for stable performance during sustained workloads

What’s in the Box

1× GEEKOM IT15 Mini PC
1× VESA Mount
1× 120W Power Adapter
1× HDMI Cable
1× User Manual

Reviews

There are no reviews yet.

Be the first to review “GEEKOM IT15 Mini PC | Intel® Core™ Ultra 9 285H”

Your email address will not be published. Required fields are marked *

Sample 1
Sample 2
Specifications

Technical Specifications

Download Technical Specifications PDF · 18.4 KB

AMD Ryzen 9 9955HX3D Processors with Radeon™ Graphics 16C/32T, TSMC 4nm FinFET, Up to 5.4 GHz; 16 MB L2 Cache/128 MB L3 Cache with 3D V-Cache,

AMD Ryzen 9 9955HX3D

AMD Radeon™ 610M On Board


+


NVIDIA GeForce RTX™ 5070 12GB GDDR7 /128bit ,6144 CUDA Cores

AMD Radeon™ 610M On Board

64GB (2x32GB) DDR5 5600, SO-DIMM*2,max 96GB

SO-DIMM*2

1x2TB SSD M.2 NVMe PCIe Gen4 x4

Max Support 8TB & PCIe5.0


1* ( xM.2 2280 PCIe Gen 5.0×4 Max Support 8TB

NVMe PCIe Gen4 x4

1x Giga LAN(RJ45) 10M/100M/1000M/2500M(RTL8125)

2500M(RTL8125)

Wi-Fi 7 (RZ717 / MT7925)

Wi-Fi 7

BT5.4

(Bluetooth)BT5.4

ספק כח 850W SFX

80 PLUS Gold

80 PLUS Gold

2x WIFI Antenna

1x power adapter

WIFI Antenna

Front Panel I/O


2 × USB-A 2.0 (480Mbps)

1 × USB-C Data Port (5Gbps)

1 × 3.5mm Audio Combo Jack (CTIA)

1 × Power Button with White LED


Rear Panel I/O


1 × HDMI 2.1 TMDS (4K@60Hz)

1 × DisplayPort 1.4 (8K@60Hz)

2 × USB-A 2.0 (480Mbps)

2 × USB-A 3.2 Gen2 (10Gbps)

1 × USB-C Data Port (10Gbps)

1 × 2.5G RJ45 LAN

2 × External Antenna Connector

1 × 3.5mm Mic-In

1 × 3.5mm Line-Out

1 × 3.5mm Line-In

1 × AC Power Connector

Rear Panel I/O | HDMI 2.1
